GPON PX+++ 8DBM(RASA)

৳ 2,650

Key Features

GPON PX+++ 8DBM (RASA)

High-Performance GPON ONT / Optical Module

FIBER OPTIC

Optical Power Output

+8dBm High Power Budget

Specification Class

PX+++ Advanced Optical Standard

Deployment Range

Long-Distance & High Split Ratios

Brand & Reliability

RASA Branded Stable Network Unit

Form Factor Support

SFP Module & Standalone ONT Bridge

Engineered for ISPs, WISP backhaul, and enterprise fiber networks.

✓

Massive Optical Budget: Overcomes extensive splitter losses and long-distance attenuation with robust signal stability.

Specifications
Details
Reviews
Videos

Specifications

Overview

Product Specifications

GPON PX+++ 8DBM

Brand	RASA
Model	GPON PX+++ 8DBM (RASA)
Device Type	GPON ONT / ONU or SFP Optical Module
Optical Standard	ITU-T G.984.x (GPON)
Optical Class	PX+++ (High Power Budget)
Transmit Optical Power	+8dBm (Nominal)
Receiver Sensitivity	Typical -30dBm to -32dBm
Optical Budget	High (38dB+ suitable for long reach)
Connector Type	SC/APC (Green) or SC/UPC (Blue)
Wavelengths	Tx: 1310nm, Rx: 1490nm
Fiber Type	Single-mode (SMF)
Downstream Rate	2.488 Gbps
Upstream Rate	1.244 Gbps
Operating Temperature	-5°C to +55°C

✓

Verified Info: RASA GPON PX+++ high-power optical module delivering +8dBm transmit power and long-reach fiber support.

Product Details

Product Description

GPON PX+++ 8DBM (RASA)

Comprehensive Technical Overview & Specifications

DETAILED GUIDE

A high-performance GPON Optical Network Terminal (ONT) or Optical Module featuring an advanced PX+++ Class optical specification with 8dBm optical power. Engineered for long-distance, high-split-ratio fiber deployments, this RASA-branded unit ensures stable network connectivity for ISPs and enterprise networks. The GPON PX+++ 8DBM (RASA) is a specialized fiber optic networking device built for challenging Passive Optical Network (PON) environments. With an optical output of +8dBm and classification under the PX+++ standard, this equipment is specifically designed for scenarios requiring extremely high optical budgets, such as long-distance transmission or networks with high split ratios (1:128 or higher).

High Optical Power Budget

Standard GPON ONTs usually operate around 0.5dBm to 5dBm. The +8dBm output of the RASA unit provides a significantly stronger signal, compensating for long fiber runs and multiple splitter losses. This makes it ideal for Fiber-to-the-Home (FTTH) deployments in rural areas where the Central Office is far from the end-user.

Rugged Network Compatibility

Designed to interface with OLTs (Optical Line Terminals) that support Class C++ or PX+++ optics, this device ensures interoperability with major OLT brands. It adheres strictly to the GPON standards set by the ITU-T G.984 series, guaranteeing stable 2.488 Gbps downstream and 1.244 Gbps upstream performance.

Application Specifics & Form Factors

This device is typically deployed in two form factors:
As an SFP Module: To be inserted into routers or switches with SFP slots for a compact, integrated ONT solution.
As a standalone ONT: A bridge or gateway device connecting the fiber line to Ethernet for home or business use.

Durable and Stable Operation

The unit is built to withstand harsh environmental conditions with a wide operating temperature range. It features robust signal filtering to reduce noise and interference, ensuring a low-latency, stable internet connection even under high optical load. It is an excellent choice for WISP (Wireless Internet Service Providers) backhaul or large MDUs (Multi-Dwelling Units).

✓

GPON PX+++ 8DBM by RASA. High power GPON ONT/Module with 8dBm output. Designed for long-distance FTTH and high split-ratio networks with massive optical budget.
