| Main Processor |
Embedded Processor |
| Operating System |
Embedded LINUX |
| IP Camera Input |
4+1 channels, each channel up to 2MP |
| Two-Way Talk |
Reuse audio in/out, RCA |
| Interface |
1 HDMI; 1 VGA |
| Resolution |
1920 × 1080, 1280 × 1024, 1280 × 720 |
| Multi-Screen Display |
When IP extension mode not enabled: 1/4
When IP extension mode enabled: 1/4/6 |
| OSD |
Camera title; Time; Video loss; Camera lock; Motion detection; Recording |
| Compression |
AI Coding/H.265+/H.265/H.264+/H.264 |
| Resolution |
1080N; 720p; 960H; D1; CIF |
| Record Rate |
Main Stream: All channels 1080N/720P/960H/D1/CIF/(1~25/30fps)
Sub stream: CIF (1~15 fps) |
| Bit Rate |
32 kbps–4096 kbps per channel |
| Record Mode |
Manual; Schedule (General, Continuous); MD (Video detection: Motion Detection, Video Loss, Tampering); Alarm; Stop |
| Record Interval |
1 min– 60 min (default: 60 min), Pre-record: 1 s–30 s, Post-record: 10 s–300 s |
| Trigger Event |
Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips |
| Video Detection |
Motion Detection, MD Zones: 396 (22 × 18), Video Loss, Tampering and Diagnosis |
| Alarm Input |
N/A |
| Relay Output |
N/A |
| Sync Playback |
1/4 |
| Search Mode |
Time/Date; Alarm; MD and Exact Search (accurate to second) |
| Playback Function |
Play; Pause; Stop; Rewind; Fast play; Slow Play; Next File; Previous File; Next Camera; Previous Camera; Full Screen; Repeat; Shuffle; Backup Selection; Digital Zoom |
| Backup Mode |
USB Device/Network |
| Third Party Support |
Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more |
| Interface |
1 RJ-45 Port (100 Mbps) |
| Network Function |
HTTP; HTTPS; TCP/IP; IPv4/IPv6; 3G/4G; UPnP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; PPPoE; DDNS; FTP; Alarm Server; P2P; IP Search |
| Maximum User Access |
128 users |
| Smart Phone |
iPhone; iPad; Android |
| Interoperability |
ONVIF 16.12, CGI Conformant |
| Internal HDD |
1 SATA port, up to 6 TB capacity |
| eSATA |
N/A |
| USB |
2 USB ports (USB 2.0) |
| RS232 |
N/A |
| RS485 |
N/A |
| Power Supply |
DC 12 V/1.5 A |
| Power Consumption |
< 7 W |
| Operational Conditions |
–10 °C to +45 °C, 0%–90% (RH) |
| Storage Conditions |
–20 °C to +70 °C, 0%–90% (RH) |
| Dimensions |
Cooper 1U, 198 mm × 202.9 mm × 41.5 mm |
| Net Weight |
0.57 kg (1.25 lb) |
| Gross Weight |
1.08 kg (2.38 lb) |
| Manufacturing Warranty |
1 Year |
