Specifications

Networking

Full Specifications

SFP Module

Module Type	SFP (Small Form-factor Pluggable)
Standard	IEEE 802.3ah (EPON)
Class	PX20++++ / C++++
Output Power	+10 dBm (Typical)
Data Rate	1.25 Gbps (Symmetric)
Wavelength	Tx: 1490nm / Rx: 1310nm
Connector	SC/UPC (Single Fiber)
Max Distance	20 KM
Monitoring	DDM (Digital Diagnostic Monitoring) Supported

✓

Verified Info: All specs aligned with official manufacturer standards.

Product Details

Product Overview

10dBm EPON OLT SFP Module

High-Capacity Optical Budget & FTTH Performance

SFP

Maximize your network reach with the 10dBm EPON OLT SFP. In modern FTTH architectures, signal loss across splitters and connectors is a common challenge. This module provides a massive optical budget, allowing ISPs to serve more subscribers per PON port without compromising on speed or uptime.

Superior Link Budget & Splitting Ratio

The +10dBm output power allows for a higher "power margin," meaning your network stays online even if there are slight imperfections in the fiber splicing or aging cables. Effortlessly supports 1:64 and 1:128 splitting ratios, helping you reduce the overall cost of OLT hardware.

Industrial Stability & Diagnostics

Designed with a robust metal housing for superior heat dissipation, ensuring 24/7 reliability in high-traffic server environments. Full DDM support allows network administrators to monitor the health of the fiber link, including temperature and optical power levels.

✓

Get reliable optical performance with 10dBm EPON OLT SFP (Includes 01 year warranty).
